Ministerial Leisure Centre in Riyadh (Saudi Arabia) | Membrane | Saudi arabia

\""
1
2
3
4
5











General information
Location address Riyadh
Location country Saudi arabia
Name of the client/building owner Kingdom of Saudi Arabia
Function of building Entertainment & recreation
Degree of enclosure Open structure
Number of layers multi-layer
Short description of the project Design

The swinging forms of the double-layer membrane roof and the glass walls of the leisure centre contrast pleasently with the rectangular geometry of the Ministry for Municipal and Rural Affairs, on which it was erected as a penthouse structure. It creates a relaxed, luxurious atmosphere. With its shape the roof reminds one also of the traditional Bedouin tents of the Arabian peninsula, which form an essential part of the local cultural heritage.

Situation, use:
The penthouse structure houses a number of different leisure areas for the employees of the ministry, ranging from a common room, to various sports areas and a sauna. The large free span allows a flexible space concept. The different areas form enclosed spaces in an open-plan area. For the interior design and fittings floor and wall toles made of natural stone fom local quarries were used, together with cherry-wood furniture costum-made in the USA. A special requirement was that the should not be seen from the ground. Its maximum inside height is 6,7 m with a covered plan area of 716 m▓.

Air conditioning
A ventilation floor serves as plenum for the air conditioning, with air outlet grilles along the external walls. In the squash courts additional air is blown in from above. An inner skin of glass fibre fabric improves the effect of the air conditioning and thus helps to save energy.

Structure
Six planar arches form the primary structure which carries the double-layer membrane roof with a maximum span 0f 18,2 m. The arches in plan are arranged perpendicularly to the curved longitudinal axis of the building and are supported by bifurcating tree columns made from steel tube. Two smaller, symmetrical arches with two simple tree columns are arranged at the narrow building sides; four larger arches, arranged in pairs in the middle part of the building, have one of their supports on the roof slab and the other on a single-story blockwork construction, which contains changing and ancillary rooms. Statically the arches are two-pin frames; the arch supports are pinned perpendicularly to their plane which meant they could be assembled lying on the floor and then set up vertically. Prestressing devices for the membrane are connected at the arch ends, to enable later tensioning along the arches.

Guy structure
Between the arches the membrane is either tied down through a simple cable guy structure with a short steel tube mast or else through a 'wishbone' structure. This is composed of two closed curved steel tube columns, which together form a pointed arch ('wishbone').

Roof membrane
The internal and external roof membranes are made of PTFE-coated glass fibre fabric; a PVC-coated polyamide fabric forms the connection between fašade and outside membrane.

Production, assembly
During the design phase a model was built out of cork slabs, wire, stretch fabric and flexible plastic bars for the arches. After approval from the Ministry the final design was carried out in cooperation with several offices in the USA and in Europe. The glass fibre fabric was made in New York state, the steel work came from England, cables and fittings from Germany, and the glass fašade was manufactured in Texas. After the reinforced concrete slab of the existing building had been strengthened, the leisure centre was assembled and erected within a month.

[Soft Shells, Hans-Joachim Schock, p75.76]
Misc. project details
References Ministerial Leisure Centre, Riyadh, Saudi Arabia - Soft Shells
Rooftop Recreation Centre, Riyadh, Saudi Arabia - Architectural Design
Duration of use
Temporary or permanent structure Permanent
Material of the cover
Cable-net/Textile/Hybrid/Foil Fabric
Material Fabric/Foil Fiberglass
Material coating PTFE
Main dimensions and form
Covered surface (m2) 716
Total length (m) 18
Involved companies
Architects FTL Happold
