Floating Pavilion in Groningen (Netherlands) | | Membrane | Netherlands

\""
1
2
3
4
5
6
7
8
9
10
11





General information
Location address Groningen
Location country Netherlands
Function of building Entertainment & recreation
Climatic zone Temperate - cold winters and mild summers
Short description of the project The floating pavilion was designed as a stage for various events and can be towed to different locations on the canals of Groningen. Its architectural form was inspired by concepts of movement, dream , surprise, etc. The raft-like concrete structure at the base - 25m long, 6m wide and 2,8m high - houses dressing rooms, sanatary facilities and accomodation for performers. Its top surface forms the stage, om each of the long edges of which is a single row of high-backed, folding metal seats. The roof consists of two spiral elements that coil in opposite directions, with a translucent polyester membrane spanned between them. It conveys an impression of lightness and makes this mobile pavilion a striking spectacle in its own.

[Detail 8/1998, Mobile Structures, p 1428]
Misc. project details
References Floating Pavilion, Groningen - DETAIL 1998/8
Duration of use
Temporary or permanent structure Permanent
Convertible or mobile Convertible and mobile
Design lifespan in years 00-05
Material of the cover
Cable-net/Textile/Hybrid/Foil Foil
Material Fabric/Foil Polyester
Material coating PVC
Main dimensions and form
Covered surface (m2) 150
Total length (m) 25
Total width (m) 6
Involved companies
Architects Maki and Associates
Engineers Structural Design Group Corp.
Editor
Editor Marijke Mollaert
